| Khối lượng | Xấp xỉ. 2,4 kg (5 lb 4,7 oz) (cơ thể) Khoảng. 2,8 kg (6 lb 2,8 oz) (có nắp đậy ống kính, eyecup, pin BP-U30, thẻ nhớ SxS) |
| Kích thước (W x H x D) * 1 | 168 × 161 × 331 mm (6 5/8 x 6 3/8 x 13 1/8 inch) (không có nhô ra) |
| Yêu cầu về nguồn | DC12 V |
| Sự tiêu thụ năng lượng | Xấp xỉ. 18 W (trong khi quay với Tắt LCD, Bật EVF, Tắt / Tắt I / O và Tắt chức năng không dây) Khoảng. 23 W (trong khi quay với màn hình LCD Bật, Tắt EVF, đầu ra HD-SDI và Chức năng không dây Bật) |
| Nhiệt độ hoạt động | 0 ° C đến 40 ° C (32 ° F đến 104 ° F) |
| Nhiệt độ lưu trữ | -20 ° C đến + 60 ° C (-4 ° F đến + 140 ° F) |
| Thời gian hoạt động của pin | Với bộ pin BP-U90: xấp xỉ. 4.5 giờ Với bộ pin BP-U60: xấp xỉ. 3 giờ Với bộ pin BP-U30: xấp xỉ. 1,5 giờ |
| Recording Format (Video) | |
| exFAT | Chế độ XAVC-I: CBG, CPC 112Mbps, MPEG-4 H.264 / AVC - 1920x1080 / 59.94i, 50i, 29.97P, 23.98P, 25P - 1280x720 / 59.94P, 50P Chế độ XAVC-L 50: VBR, tối đa. 50Mbps, MPEG-4 H.264 / AVC - 1920x1080 / 59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P - 1280x720 / 59.94P, 50P Chế độ XAVC-L 35: VBR, tối đa. 35Mbps, MPEG-4 H.264 / AVC - 1920x1080 / 59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P Chế độ XAVC-L 25: VBR, tối đa. 35Mbps, MPEG-4 H.264 / AVC - 1920x1080 / 59,94i, 50i |
| exFAT | Chế độ MPEG HD422: CBR, 50Mbps, MPEG-2 422P @ HL - 1920x1080 / 59.94i, 50i, 29.97P, 23.98P, 25P - 1280x720 / 59.94P, 50P, 29.97P, 23.98P, 25P MPEG HD420 Chế độ HQ: VBR , tối đa 35Mb / giây, MPEG-2 MP @ HL - 1920x1080 / 59,94i, 50i, 29,97P, 23,98P, 25P - 1440x1080 / 59,94i, 50i, 29,97P, 23,98P, 25P - 1280x720 / 59,94P, 50P, 23,98P (2 -3 Kéo xuống) Chế độ DVCAM: CBR, 25Mbps, DVCAM - 720x480 / 59.94i, 29.97PsF - 720x576 / 50i, 25PsF |
| UDF | Chế độ MPEG HD422: CBR, 50Mbps, MPEG-2 422P @ HL - 1920x1080 / 59.94i, 50i, 29.97P, 23.98P, 25P - 1280x720 / 59.94P, 50P, 29.97P, 23.98P, 25P MPEG HD420 Chế độ HQ: VBR , tối đa 35Mb / giây, MPEG-2 MP @ HL - 1920x1080 / 59,94i, 50i, 29,97P, 23,98P, 25P - 1440x1080 / 59,94i, 50i, 29,97P, 23,98P, 25P - 1280x720 / 59,94P, 50P, 23,98P (2 -3 Kéo xuống) Chế độ MPEG IMX50: CBR, 50Mbps, MPEG-2 422P @ ML Intra - 720x486 / 59.94i, 29.97PsF - 720x576 / 50i, 25PsF Chế độ DVCAM: CBR, 25Mbps, DVCAM - 720x480 / 59.94i, 29.97PsF - 720x576 / 50i, 25PsF |
| FAT | MPEG HD420 HQ mode: VBR, max. 35Mbps, MPEG-2 MP@HL - 1920x1080/59.94i, 50i, 29.97P, 23.98P, 25P - 1440x1080/59.94i, 50i, 29.97P, 23.98P, 25P - 1280x720/59.94P,50P, 29.97P, 25P, 23.98P MPEG HD420 SP mode: CBR, 25Mbps, MPEG-2 MP@H-14 - 1440x1080/59.94i, 50i, 23.98P(2-3 Pull Down) DVCAM mode: CBR, 25Mbps, DVCAM - 720x480/59.94i, 29.97PsF - 720x576/50i,25PsF Proxy: H.264 - 1280x720: 9Mbps - 640x360: 3Mbps - 480x270: 1Mbps - 480x270: 500Kbps |
| Recording Format (Audio) | |
| exFAT | XAVC-I mode: LPCM 24-bit, 48kHz, 4ch XAVC-L mode: LPCM 24-bit, 48kHz, 4ch MPEG HD422 mode: LPCM 24-bit, 48kHz, 4ch MPEG HD420 HQ mode: LPCM 16-bit, 48kHz, 4ch DVCAM mode: LPCM 16-bit, 48kHz, 4ch |
| UDF | MPEG HD422 mode: LPCM 24-bit, 48kHz, 4ch MPEG HD420 HQ mode: LPCM 16-bit, 48kHz, 4ch IMX50 mode: LPCM 24/16-bit, 48kHz, 4ch DVCAM mode: LPCM 16-bit, 48kHz, 4ch |
| FAT | MPEG HD420 HQ mode: LPCM 16-bit, 48kHz, 4ch MPEG HD420 SP mode: LPCM 16-bit, 48kHz, 4ch DVCAM mode: LPCM 16-bit, 48kHz, 2ch Proxy: AAC-LC, 48kHz, 128kbps, 2ch |
| Ống kính | |
| Lens Mount | Fixed |
| Zoom Ratio | 17x (optical), servo/manual |
| Focal Length | f = 5.6-95.2 mm (35 mm equivalent: 29.3-499 mm) |
| Iris | F1.9-F16 and close, auto/manual selectable |
| Focus | 800 mm to ∞ (Macro Off), 50 mm to ∞ (Macro On, Wide), 800 mm to ∞ (Macro On, Tele), AF/MF/Full MF selectable |
| Image Stabilizer | On/Off selectable, shift lens |
| Filter Diameter | M77 mm, pitch 0.75mm |
| Phần camera | |
| Imaging Device (Type) | 3-chip 1/2-inch type “Exmor” Full HD CMOS |
| Effective Picture Elements | 1920 (H) x 1080 (V) |
| Built-in Optical Filters | Clear, 1: 1/8ND, 2: 1/64ND |
| Sensitivity | F12 (typical, 1920 x 1080/59.94i mode) F13 (typical, 1920 x 1080/50i mode) |
| Minimum Illumination | 0.09 lx (typical, 1920x1080/59.94i, F1.9, +18 dB gain, with 64-frame accumulation, Gamma off, 100% video level) 0.02 lx (typical, 1920x1080/59.94i, F1.9, +18 dB gain, with 64-frame accumulation, Gamma on, 50% video level) |
| S/N Ratio | 58dB (Y) (typical) |
| Shutter Speed | 1/32 sec to 1/2,000 sec |
| Slow & Quick Motion Function | XAVC Intra/Long mode: - 1080P: 1-30 and 60 fps in NTSC setting, 1-25 and 50 fps in PAL setting - 720P: 1-60 fps in NTSC setting, 1-50 fps in PAL setting MPEG HD422 mode: - 1080P: 1-30 fps in NTSC setting, 1-25 fps in PAL setting - 720P: 1-60 fps in NTSC setting, 1-50 fps in PAL setting MPEG HD420 HQ mode: - 1080P: 1-30 fps - 720P: 1-60 fps |
| White Balance | Preset (3200K), Memory A, Memory B/ATW |
| GPS*2 | Yes |
| Wireless functions | Yes |
| NFC | Yes |
| Input/Output | |
| Audio Input | XLR-type 3-pin (female) (x2) |
| HDMI Output | Type A (x1) |
| SDI Output | BNC (x1), 3G/HD/SD selectable |
| Composite Output /GENLOCK-IN | BNC (x1) |
| Audio Output | A/V multi connector (x1) |
| USB | USB device, mini-B (x1) |
| TC in/out | BNC (x1) |
| Lens Remote | 8-pin, round (x1) |
| DC Input | DC jack (x1) |
| Shoe | Multi Interface Shoe (x1) |
| Headphone Output | Stereo mini jack ø3.5mm (x1) |
| Option | 4-pin Type A (x1) |
| Monitoring | |
| Viewfinder | 0.45-inch type color LCD: 852 (H) x 480 (V), 16:9 |
| LCD | 3.5-inch type color LCD monitor: 960 (H) x 3 (RGB) x 540 (V), 16:9 |
| Built-in Microphone | |
| Built-in Microphone | Omni-directional stereo electret condenser microphone |
| Media | |
| Type | ExpressCard/34 slot (2) (for XAVC/MPEG/IMX/DV) SD/SDHC (1) (for Proxy) |
| Supplied Accessories | |
| Supplied Accessories | Lens hood (1), pre-installed to the Camcorder EVF large eyecup (1), pre-installed to the Camcorder Infrared Remote Commander (1) Wireless LAN module IFU-WLM3 (1) Accessory shoe kit (1) Battery pack BP-U30 (1) Battery charger BC-U1 (1) Power Code (1) USB cable (1) Audio connecting cable (1) Shoulder strap (1) Lithium battery (CR2032 for data backup) (1), Pre-installed to the Camcorder Lithium battery (CR2025 for the IR Remote Commander) (1), Pre-installed to the IR Remote Commander Warranty booklet (1) “Before Using this Unit” (1) CD-ROM “Operating instructions” (1) |
| Optional Accessories | |
| Optional Accessories | BP-U30/BP-U60/BP-U60T/BP-U90 Rechargeable Battery pack, BC-U1/BC-U2 Battery Charger/AC Adaptor, HVL-LBPC Battery Video Light, UWP-D11/UWP-D12 Wireless Microphone Package, SBS-64G1A/SBS-32G1A SxS-1 Memory Cards, QD-G128A/QD-G64A/QD-G32A, XQD G Series Memory Cards SBP-128B/SBP-64B SxS PRO+ Memory Cards MS-HX32B/MS-HX16B/ MS-HX8B Memory Stick PRO-HG Duo™, ECM-VG1 Electret Condenser Microphone, SMAD-P3 MI Shoe Mount Adaptor* required for cable-free operation with UWP-D11/UWP-D12, QDA-EX1 XQD ExpressCard Adaptor, ECM-MS2 Electret Condenser Microphone, MEAD-SD02 SD Card Adaptor for XDCAM Series, ECM-673 Electret Condenser Microphone, MEAD-MS01 Memory Stick Adaptor for XDCAM EX. |
